3PCS/Lots BIQU TL-Smoother V1.0 Filter Module Expansion Board For 3D Printer Driver

Brand Name: BIQU
Model Number: ZMK000003
Name: TL-Smoother
Fit to: 3D Printer
Place of origin: China
Size : 40*30
Type: Voltage Regulator



The BIQU TL-Smoother V1.0 is a simple yet effective addon filter module for 3D printer stepper motor drivers. It adds flyback (freewheeling) diodes to the motor outputs, protecting the driver and providing smoother stepper movement, especially when using older drivers like A4988 or DRV8825.

Key Features:

• Reduces motor vibration and noise for quieter operation
• Improves print surface quality by minimizing “salmon skin” artifacts and chatter
• Provides protection against inductive voltage spikes
• Especially effective on delta-style printers and with A4988/DRV8825 drivers
• Easy plug-in design between the driver and stepper motor
• Compact size (approx. 40×30mm) for clean installation
• Available in 1pc, 3pcs, or 4pcs packs for single-axis or full printer upgrades

This low-cost upgrade is popular among users of older stepper drivers who want better print quality and reduced noise without upgrading to silent TMC drivers.









The TL-Smoother is an addon module for 3D printer stepper motor drivers.



The board provides flyback diodes (freewheeling diodes) for the motor  outputs,



so that they are also protected against induction voltages  in the unpowered  state



of the driver.You will got smoother movement especially  on the delta-style  3Dprinter



under DVR8825 stepper drivers and A4988/2  drivers.



Lower vbration lower noise  smoother result！



TL-Smoother assembly instructions





https://drive.google.com/open?id=1Kdq4FKcv4PRkuYbeoWxF_myPKDdfZud9XCIloQEaLqs









• Package Weight: 0.06kg (0.13lb.)
•
• Package Size: 12cm x 12cm x 12cm (4.72in x 4.72in x 4.72in)
